AUTOMATIC DROP MACHINES FOR BISCUIT AR 52-4W JAPANESE MACHINERY

	Price: 144663 $ Quantity: Add to cart	Manufacturer: JAPAN MACHINERY SYSTEM Model: AUTOMATIC DROP MACHINES FOR BISCUIT AR 52-4W JAPANESE MACHINERY

Details

AR 52 JAPANESE COOKIE DEPOSITOR



The System featuring the six blade rotary feeding unit has neither harms nor damages on the dough

Simple and easy to operate

Easier to wash and clean

Enable you to form a wide variety of squeeze varying from cakes up to cookies possible by just a single unit

Applications by using regular type of nozzles

1/ Choux

2/Cream puff

3/Eclairs

4/Madeleines

5/Cup Cake

6/Swiss Rolls

7/Fruit Cakes

8/Charlotte

9/Bouchee

By using a valve system for pulpy materials

Decoration Bases

Cheese cakes

Sponge sheets

Siphon Cake

Steamed cake

Madeleine

Mousse

Financiere

FEATURES

A touch panel method makes it possible to store in memory the filling data for all kinds of products respectively

Six bladed rotary feeding methods has no harms nor damage on the dough while applicable to almost all kinds of material

Nozzle exchange is very simple and therefore various usages are possible

A standard unit is equipped with a conveyor for an Automatic forwarding system of the pans

Just in case, it is possible to arrange for automatic filling into a band oven following after this unit and also combine it into the production line already set up

Demounting the filling unit is simple and the whole item can be disassembled completely which would guarantee you to provide sanitary washing and cleaning in a short time

Possible to reverse the motion of the conveyor toward the nozzle side after having deposited

Squeezing works for cookie making are possible by the exchange of the filling unit

Special specifications are available from us upon request

Model :AR 52 Depositor -4W

Filling Amount : 800 cc/one cycle

Capacity : 4 to 6 pans per minute

Width of Cookies : 300-400 mm in width

Depth of Cookies : 100 mm Maximum

Hooper : 45 Liter

Conveyor speed : Variable ( Maximum 220 mm per second )

Power : 1 Kw

Frequence : : 50-60 Hertz

Source of air: 5kgf-cm2 (In case use of valve )

Weight : 300 Kg

Width : 1130 mm

Depth : 1380 mm

Height : 1620 mm

Product Information Manufacturer: JAPAN MACHINERY SYSTEM Model: AUTOMATIC DROP MACHINES FOR BISCUIT AR 52-4W JAPANESE MACHINERY Horse power: 1 kw Phases: 3 : Voltage: 240 volts Frequence: 60 Hz

Dimensions Width: 1130 mm Depth: 1380 mm Height: 1620 mm Weight: 300 Kg
