Single Racks Gas Oven Model LR0-1G

	Price: 27948 $ Quantity: Add to cart	Manufacturer: LANG Model: Single Racks Gas Oven Model LR0-1G

Details

Single Rack Oven MODEL: LRO-1G

Construction Features

. Heavy duty stainless steel interior

. Cooking compartment insulated with 5" thick high-temp insulation

. Fully integrated hood with single point exhaust connection

. Automatic, heavy-duty "B" style lift and rotate system

. Heavy-Duty gear driven rotation system

. Heavy-duty door with 9.75" x 57.5" viewing window

. Interior door safety release mechanism

. Accommodates one single rack

Performance Features

200-550 Degree F temperature range

Vertiflow heatexchanger uses natural draft for combustion air

High volume, waterfall type steam system

Burner manifold uses in-shot burners and hot surface ignition

Adjustable air circulation louvers

Self adjusting slip clutch protects operator and prevent component damage

Automatic rack stop and lower when door is opened

Floor level loading without ramps

Integrated Hood Features and Performance

Meets the construction requirements of NFPA 96 & UMC requirements for

Type I & II Hoods, fire systems when required, shall be by others. 20 Ga. welded stainless steel body

Controls Package

Standard Graphic Display Control

Manual or programable modes

60-programable recipe w/5-events per recipe

Infrared port for uploading and downloading programs

Flash type programing for revision updates without replacing PCB

Large LCD event screen for programming and oven status Auto start

Cool-down feature

Optional PC - USB flash drive programing port (for standard control only)

Optional LED Display Control

99-Programable Recipes

Short Bid Specification: . Large LCD event screen for programming and oven status

. Auto start

. Cool-down feature .

. Optional LED Display Control

. 99-Programable Recipes

. Single Event

Steam / Vent / Blower delay or pulse

One-Year Warranty

Rack oven shall be an Model LRO-1G 175,000 BTU/Hr. gas heated rotating, single rack capacity unit with; vertifow heat

exchanger; waterfall type steam generation system; 5' thick compartment

insulation rated at 0" combustible wall clearance; heavy-duty rack lift and rotate system with gear driven rotation system; simple solid state controls,

with digital time-temperature readouts, 5 event menu programs for time,

temperature, steam, vent and blower function, 60-menu program memory

an integrated hood meeting NFPA 96 and Type I & II construction standards, plus all the features listed:

MODEL / RACK CAPACITY

Maximum Capacity

18" x 26" Full-size Sheet Pans*: 20

12" x 20" x 4" Hotel Pans** : 20

1 Lb. Loaves of Bread : 100

1 1/2 Lb. Loaves of Bread : 75

INSTALLATION REQUIREMENT

Oven ships one-piece but can be split for movement through 36" opening



Phase for circulation Blower

1" NPT Gas Connection 5" - 14" W.C.

1/2" NPT Water Connection

3/4" NPT Vented drain



Specify natural gas or LP gas

Width 1398 mm

Depth 22352 mm

Height 26416 mm

Voltage : 240 V

Fréquence : 60 Herzt

Power : 1,5 Kw

Phase : 1

Product Information Manufacturer: LANG Model: Single Racks Gas Oven Model LR0-1G

Dimensions Width: 1398 mm Depth: 22352 mm Height: 26416 mm Weight: 2500 Kg

Shipping Information
